What are we doing

Prime Marble's new patented S.A.M. marble slab finishing machine is a world first. Through a revolutionary and patented processing method, it manages to quickly identify veins or imperfections in slabs, easily eliminate them and retouch them perfectly.  And all this in a fully automated, unique process. Former rejects or poor quality can now be upgraded and sold at a profit. Prime Marble's new technology revolutionizes the marble slab sales market and makes an important contribution in terms of resource conservation and sustainability by drastically reducing marble slab rejects. Vein processing is fully automated, with up to six processing steps optional and individually configurable. Convince yourself. We will be happy to advise you.

How it works

1. Intelligent scanning of the slab


A high-precision, high-tech camera system captures the entire vein structures and automatically offers the operator an initial correction suggestion, which the operator can modify individually. The machine thus "learns" the operator's individual criteria over time and provides ever better, automatic correction suggestions.

2. High-precision removal of veins


The selected veins are lasered out fully automatically. Significantly faster, more precise and safer than with conventional methods used to date.

3. Thorough cleaning


The lasered plate is then thoroughly cleaned with compressed air and brushes to be ready for the next processing step.

4. Perfect retouching


An intelligent high-performance printing system is used to retouch the processed areas are retouched. The result is an unprecedented optical quality.

5. Protective sealing


After printing, the processed areas are insulated and permanently sealed with a filling material commonly used in the market.

6. Sanding and high gloss polishing


The sealing is followed by a fully automatic complete sanding of the entire panel and a high-gloss polishing. The grinding and polishing module is optional and can be omitted if desired, provided that appropriate machines are already available.

Types of Machine
 There are two different sizes of the machine depending on the size of slabs.

*depends on effort

S.A.M.

For 1,2 m x 1,2 m slabs


Length: ~ 14 m

Width: 3,2 m

Capacity:  200 - 400 m² per 12h*

S.A.M. +

For 1,85 m x 3,25 m slabs


Length: 32 m

Width: 3,8 m

Capacity: 500 - 1000 m² per 12h*
